VENUS V

The all-electric Venus V Series machines are available in sizes from 400 kN to 13800 kN and with possible injection speeds up to 500 mm/s. Due to such parameters you get high quality, precise and extremely repeatable workpieces at an attractive price/performance ratio. Tailor-made electric servo drive systems with high dynamics and precision, combined with a new generation of inverters, ensure high production efficiency. The third generation of Zhafir technology is a system platform with intelligent and extremely fast adaptive software. Sigmatek controllers, used in Venus Series, enable open integration and communication with all popular interfaces and seamless connection of industrial automation or any MES system.

All-electric

400 - 13 800kN

All-electric drives for dynamic and quiet operation

Intelligent motion control for short dry cycle times

Main benefits


Stable injection speed

High injection molding stability, optimum servo dynamics and injection speed control.




Precision and repeatability

Linear guides provide reduced friction coefficient during mold movements, clean working space, accurate position control and repeatability.


MOTION PLUS mold protection

Intelligent algorithms provide highly reactive and precise mold protection.



Standard technical specification of the VENUS series

Clamping Unit
  • 5-point twin toggle mechanism
  • Center pressing platen
  • Clamping force settable at control panel
  • Automatic mold-height adjustment
  • Platen moving speed 6 steps
  • Full stroke mold protection
  • Clamping force pre-release
  • Ejector speed 3 steps
  • Ejector pressure 3 steps
  • Multi ejection function
  • Ejection parallel to mold opening
Injection Unit
  • Abrasion-resistant screw set, general version
  • Open nozzle
  • Barrel heating  PID control, SSR
  • Extended nozzle, temperature PID control independently
  • Feeding zone temperature closed-loop control
  • Injection speed 6 steps
  • Speed responding mode adjustable
  • Holding pressure 4 steps
  • Pressure responding mode adjustable
  • V/P switch over methods by position/ time/ pressure combinations
  • Dosing rotation speed 3 steps
  • Back pressure 3 steps
  • HPM over-filling protection function
  • Screw retraction before and/or after dosing
  • Auto purge
  • Swiveling injection unit
Functions & Controls
  • Multi-language available (Chinese, German, English, Japanese etc.)
  • Metric/Imperial unit selectable
  • Dosing parallel to mold opening
  • Injection compression
  • Production assistant device function
  • Maintenance alert
  • 5000 cycles process data recording
  • Amendment report
  • Alarm record
  • Quality control function
  • Mold profile data memory (up to 200 sets)
  • 3 USB interface
  • USB printer interface
  • Injection speed & pressure curve
  • 1 free programmable I/O
  • Mold ejector protection interface
  • EUROMAP 12 interface for handling device
  • Auxiliary socket 3PH/380V 32A×1, 16A×2
  • 3 color alarm lamp (red/yellow/green)
